L293D IC
- Applications of L293D Dual H- Bridge Motor Driver IC
- High Current Motor Driver IC
- Dual H-bridge for controlling up to two motors at a time
- Wide voltage range allows for an adaptive voltage range control
- Function: Driver IC for DC Motors
- Pin number: 16
₹37.00
L293D IC is a bidirectional motor driver IC means it can drive DC motor to rotate or run in either direction. This ic can drive 2 motors simultaneously in either direction by 1 IC. It is also known as Dual H-bridge Motor Drive IC. The reason because of that L293D driver IC mostly used is it can drive any time of motor, like big as well small.
Technical Specifications
- Wide Supply-Voltage Range: 4.5 V to 36 V
- Separate Input-Logic Supply
- Internal ESD Protection
- Thermal Shutdown
- High-Noise-Immunity Inputs
- Output Current: 1 A Per Channel
- Peak Output Current: 2 A Per Channel
- Output Clamp Diodes for Inductive
